DW1 – ABB
DW1 – ABB
Technical
- Standards:
- EN 60730-2-7
EN-301 489-17
EN-300 328
EN-62479
EN 50581
- Product Name:
- Digital Time switch
- Function:
- Weekly
- Rated Operational Voltage:
- 115 … 230 V AC
- Operational Voltage:
- 195 … 253 V AC
- Rated Impulse Withstand Voltage (Uimp):
- Maximum 4 kV
- Maximum Switching Current:
- 16 A
- Rated Frequency (f):
- 50 … 60 Hz
- Maximum Switching Power:
- 4000 V·A
- Power Consumption (@Pcons):
- 2 W
- Power Loss:
- 2 W
- Power Supply:
- 230 V AC
- Accuracy:
- ± 0.5sec/24h
- Number of Channels:
- 1
- Maximum Number of Programs:
- 120
- Tightening Torque:
- 0.5 N·m
- Minimum Switching Time:
- 1 minute [unit of time]
- Contact Type:
- Change-Over (CO)
- Meter Type:
- Digital
- Mounting Type:
- DIN rail
- Options Provided:
- With running reserve
- Battery Chemical Composition:
- Lithium
- Battery Life:
- 5 year
- Battery Type:
- Button Cell
- Battery Weight:
- 0.003 kg
- Number of Batteries:
- 1
- Connecting Capacity:
- Solid 2.5 mm²
Environmental
- Ambient Air Temperature:
- Operation -20 … +50 °C
Storage -25 … +70 °C
- Degree of Protection:
- Housing IP20
Dimensions
- Width in Number of Modular Spacings:
- 2
- Product Net Width:
- 35 mm
- Product Net Height:
- 65 mm
- Product Net Depth / Length:
- 87 mm
- Product Net Weight:
- 0.129 kg
Container Information
- Package Level 1 Units:
- 1 piece
- Package Level 1 Width:
- 60 mm
- Package Level 1 Height:
- 80 mm
- Package Level 1 Depth / Length:
- 97 mm
- Package Level 1 Gross Weight:
- 0.210 kg
- Package Level 1 EAN:
- 8012542225317
Ordering
- Minimum Order Quantity:
- 1 piece
- Customs Tariff Number:
- 85364900
- E-Number (Finland):
- 2619406
- E-Number (Sweden):
- 1330650
- Country of Origin:
- Italy (IT)
- Selling Unit of Measure:
- piece
Certificates and Declarations (Document Number)
- Declaration of Conformity – CE:
- 2CSC441018D2701
- Instructions and Manuals:
- 2CSM441050D0201
Popular Downloads
- Data Sheet, Technical Information:
- 9AKK107991A8329
- Instructions and Manuals:
- 2CSM441050D0201
Classifications
- ETIM 6:
- EC002305 – Digital time switch for distribution board
- ETIM 7:
- EC002305 – Digital time switch for distribution board
- ETIM 8:
- EC002305 – Digital time switch for distribution board
- WEEE Category:
- 5. Small Equipment (No External Dimension More Than 50 cm)
- WEEE B2C / B2B:
- Business To Consumer
- CN8:
- 85364900
- Object Classification Code:
- K
