F202-AC-25-0-03
F202-AC-25-0-03
Technical
- Standards:
- IEC/EN 61008
UL 1053
- Product Name:
- Interruptor diferencial
- Type of Residual Current:
- AC type
- Rated Voltage (Ur):
- 230 V
- Rated Operational Voltage:
- 230 V
- Rated Insulation Voltage (Ui):
- 500 V
- Rated Impulse Withstand Voltage (Uimp):
- 4 kV
- Rated Current (In):
- 25 A
- Rated Residual Current:
- 30 mA
- Rated Conditional Short-Circuit Current (Inc):
- 10 kA
- Rated Service Short-Circuit Breaking Capacity (Ics):
- 1 kA
- Maximum Surge Current:
- 0.25 kA
- Leakage Current Type:
- AC
- Rated Frequency (f):
- 50 / 60 Hz
- Power Loss:
- at Rated Operating Conditions per Pole 1 W
- Power Supply Connection:
- Arbitrary
- Electrical Endurance:
- 10000 cycle
- Number of Poles:
- 2
- Operating Characteristic:
- Instantaneous
- Mounting Type:
- DIN rail
- Options Provided:
- None
- Accessories Available:
- Yes
- Connecting Capacity:
- Busbar 10 mm²
Rigid 25 … 25 mm²
Flexible 25 … 25 mm²
- Rated Cross-Section:
- 4 – Multi-Wired 0…25 mm²
1 – Solid-Core 25…25 mm²
Ambiente
- Ambient Temperature:
- -25…55 °C
- Temperatura ambiente:
- Funcionamiento -25…55 °C
- Grado de protección:
- IP2X
- Pollution Degree:
- 2
- RoHS Status:
- Following EU Directive 2011/65/EU
- Environmental Information:
- Refer to RoHS
Technical UL/CSA
- Maximum Operating Voltage UL/CSA:
- 277 V AC
- Short-Circuit Current Rating (SCCR):
- 0.03 A
Dimensiones
- Width in Number of Modular Spacings:
- 2
- Ancho del product:
- 0.035 m
- Alto del producto:
- 0.085 m
- Largo del product:
- 0.069 m
- Peso del product:
- 0.200 kg
- Built-In Depth (t2):
- 69 mm
Información de Embalaje
- Embalaje Nivel 1 Unidades:
- box 1 piece
- Embalaje Nivel 1 Ancho:
- 80 mm
- Embalaje Nivel 1 Alto:
- 41 mm
- Embalaje Nivel 1 Largo:
- 94 mm
- Embalaje Nivel 1 Peso:
- 0.235 kg
- Embalaje Nivel 1 EAN:
- 8012542780007
Clasificación
- Cantidad mínima de pedido:
- 1 piece
- Código arancelario:
- 85363030
- Country of Origin:
- Italy (IT)
- Selling Unit of Measure:
- piece
Certificados y Declaraciones (Número de Documento)
- Declaración de conformidad – CE:
- 9AKK106713A5602
- Environmental Information:
- Refer to RoHS
- Instrucciones y manuales:
- 9AKK107991A6127
- RoHS Information:
- 2CSC423001K2702
Descargas Populares
- Ficha técnica, información técnica:
- 9AKK107991A8329
- Instrucciones y manuales:
- 9AKK107991A6127
Clasificaciones
- ETIM 6:
- EC000003 – Residual current circuit breaker (RCCB)
- ETIM 7:
- EC000003 – Residual current circuit breaker (RCCB)
- ETIM 8:
- EC000003 – Residual current circuit breaker (RCCB)
- EPLAN Catalog Tree:
- Electrical engineering / Protection devices / Ground fault current circuit breaker
- EPLAN Function Definition:
- Ground fault current circuit-breaker / Ground fault current circuit breakers, 4 connection points / Ground fault current circuit breaker, two-pole 1/2 2/1 3/4 4/3
- Categoría RAEE:
- 5. Small Equipment (No External Dimension More Than 50 cm)
- WEEE B2C / B2B:
- Business To Consumer
- CN8:
- 85363030
- Object Classification Code:
- F
